HVOF Coat Screw

HVOF Coat Screw

HVOF (High Velocity Oxygen Fuel) coating process is a kind of thermal spraying technique that melted (or heated) materials are sprayed into the surface.

Advantages

 By HVOF technology, alloy powder spraying is under high pressure and high velocity. The adhesive force is over 10000PSI, and the powder density can be achieved up to 99.8%, which offers outstanding performance in wear & corrosion resistance.



Application

Specially for Halogen-free material with below 65% glass fibre filling.

  • Description
  • Feedback
  • Technical Parameters

    Product Name

    Full Coating WC Screw

    Material

    JYG3 + Tungsten Carbide Alloy Coating

    Suitable Machine

    Injection / Extrusion / Blowing

    Available Size

    Φ14-80mm, L < 2,300mm

    Process Method

    HVOF Spray

    Surface Hardness

    1100-1400 HV

    Parameters of screw coatings

    COATING
    TYPE

    COATING
    METHOD

    COATING
    THICKNESS

    HARDNESS

    MAX.
    LENGTH

    APPLICATIONS

    TiN

    PVD

    0.002 - 0.003mm

    2000 - 2200 HV

    1900mm

    Optical products & abrasive plastics processing.

    Chrome Plate

    Electroplatings

    0.02 - 0.08mm

    650 - 720 HV

    6000mm

    Transparent products & corrosive plastics processing.

    Tungsten
    Coating

    HVOF

    1.0 - 1.5mm

    1100- 1400 HV

    2300mm

    High abrasive plastics processing.
