Tiebars

Tiebars

Our second factory, Ningbo Lichao Tiebar Precision Machinery Co., Ltd. is specialized in manufacturing nitriding and chrome plated tie bars together with matching guide rods, piston rods, nuts and other accessories for injection molding machine, die casting machine and forging machine.

Application

Injection molding machine, die casting machine and forging machine, etc.

  • Description
  • Feedback
  • Technical Parameters

    Product Name

    Tiebar or Tie Bar

    Material

    JYN3

    Heat Treatment

    Quench & Temper

    Surface Treatment

    Nitrided or Chrome Plated

    Chrome Thickness

    0.05mm

    Surface Hardness

    > 55 HRC

    Max. Diameter

    600mm

    Max. Length

    10,000mm

    Manufacturing Process

    Here is a comparison of the different manufacturing processes for nitrided and bimetallic tiebars.
